New and Used Semiconductor Equipment For Sale. Items include: Kevex Omicron XRF, Thermo Kevex X-Ray, Lufran superbowl, Branson Benchmark Series Ultrasonic Cleaner, Fisons, Wafer Inspection Stations, Mactronix wafer loader, Nikon NWL-640, Nikon Optiphot-66 Metallurgical Microscopes, Nikon & Olympus objectives for sale, Nikon Wafer Inspection Stations, Topometrix Atomic Force Microscope SPM Digital Instruments, Thermo Forma Console Clean Air WorkStation, Ontario, Canada.

  Kevex Omicron XRF
  Nikon Optiphot-66 Microscope
  Nikon Objectives
  Accu-Seal 40-233 Vacuum Sealer
  Lufran Superbowl
  Struers Minitom
  Struers Labopol-21
  Shimpo Pull Tester
  Branson UltraSonic Cleaner
  Mactronix PWS-M2 Wafer Loader
  Mitutoyo Digital Caliper Systems
  OMEGA Pressure Meters
  OMEGA Mass Flowmeters
  Newport & OptoSigma
  Vibration Isolation Table
  Clean Air Workstation

Last Site Update:
        February 22, 2010

      519.787.0489
      519.787.8063 Fax
      sales@metlabsolutions.com

We will buy your surplus semiconductor items, or, even your entire laboratory.
Please e-mail us with your list.

Kevex Omicron X-Ray Fluorescence Spectrometer for Sale

Kevex (Thermo Kevex X-Ray) Omicron XRF

SOLD

Small spot size characterization and measurement of elemental concentrations of thin films. Was used for Boron and Phosphorous content control in BPSG films.

Approximate manufacture date is 1995, was running in production FAB up to Oct 1 2002. Last serviced June 2002, in storage since then.

Pristine unit includes set-up assistance from manufacturer service technician. E-mail us for pricing.

Nikon Optiphot-66 Metallurgical Microscope for Sale

Demo condition unit with binocular headand CFW 10X eyepieces.

Manual 4 position nosepiece, BF/DF, BD PLAN 10, BD PLAN 20, BD PLAN 40, BD PLAN 100 x objectives.

Variable 3 - 6V power supply. E-mail us for pricing.

Nikon Objectives for Sale

Nikon BD Plan 10X 0.25 210/0 (3 objectives)
Nikon BD Plan 20X 0.4 210/0 (3 objectives)
Nikon M Plan 20X 0.4 LWD 210/0 (1 objective)
Nikon BD Plan 40X 0.65 210/0 (3 objectives)
Nikon M Plan 40X 0.55 LWD 210/0 (1 objective)
Nikon BD Plan 60X 0.80 210/0 (1 objective)
Nikon BD Plan 100X 0.90 Dry 210/0 (2 objectives)

In very good condition, 14 available - no scratches.

Accu-Seal 40-233 Vacuum Sealer for Sale

Used unit, new into inventory.
Photo coming soon.

Very good condition. Please e-mail for component specification and pricing.

Lufran Superbowl Bath Systems for Sale

Model SB4T-J-30-V208. 6 units available, new, still in original packaging.

Teflon immersion heater and process control module. Digital PID based temperature controller, heater purge controls, Kydex enclosure, process and overtemperature thermocouples, liquid level sensor.

Compatible with sulphuric, nitric, acetic acid solutions (virtually any process solution), KOH, HF, and various strippers.

Retails new for $4,425 USD each from Lufran. These units are new surplus, they have never been used. Please e-mail us for pricing.

Struers Minitom Cut-Off Machine for Sale

Used Miniton, excellent condition unit - new into inventory.
Gently used at a major semiconductor research facility.
Comes with chuck, 2 counterweights, and Struers RS-70308 blade.

Please e-mail us for pricing.

Struers Labopol-21 Grinder/Polisher for Sale

Used Labopol-21, excellent condition unit - new into inventory.
Gently used at a major semiconductor research facility.
Comes with numerous grinding accessories.

Please e-mail us for pricing.

Shimpo FGE-5X 5lb Pull Tester for Sale

Used Shimpo FGE-5X 5lb Pull Tester, excellent condition unit - new into inventory.
Gently used at a major semiconductor research facility.
Comes with Model FGS-50H test stand.

Please e-mail us for pricing.

Branson UltraSonic Cleaner (Bath) for Sale

BENCHMARK Model 8000 Ultrasonic Bath.
Surplus stock unit - NEVER USED.
Precision modular cleaning systems - easily add more modules to adapt to your process. Stainless steel constuction thoughout (interior/exterior). Configuration: LOAD STATION (1) S8040-18 GENERATOR, TDR INT'FCE CONTROLLER, BMO-1216, HEAT, PUMP, 40KHz SONICS, LIQUID LEVEL, 10 AMPS, 208V/3PH/60Hz.

Retailed new for over $16,000 USD. Please e-mail us for pricing.

Mactronix PWS-M2 Wafer Loader for Sale

Pristine used wafer loader, comes with platform and optional fully loaded Nikon Optiphot-66 metallurgical scope.

The wafers can be rotated 360' while on the stage adapter to allow for both micro and macro inspection. The PWS-M2 is compatible with most microscopes on the market and is available with or without a Nikon Optiphot-66.

Easy to read LCD coupled with a hand held programmer key pad allow for easy operation and quick programing. E-mail us for pricing.

Mitutoyo Digital Caliper System for Sale

Sparingly used 4" Mitutoyo ABSOLUTE DIGIMATIC digital caliper systems for sale, 12 available.

Comes with caliper to computer interface cable and PC interface card (Mitutoyo DIGI-CARD 015901A).

Mounts on microscope stage or precision machinery for accurate stage movement determinations. 0.01mm or 0.0001 inch resolution.

OMEGA HHP-805 Pressure Meters for Sale

Dealer demo condition used pressure meter.

Calibrated Accuracy: +/- 0.2% of full scale at +23 C, Repeatability: +/- 0.1% of full scale at +23 C. Range 0 to +/- 30 PSI, 0 to +/- 2000 mbar Differential.Max over/under pressure range = 90 PSI/6200 mbar.
Has ON/OFF Key, ZERO Key, SCALE Key, HOLD Key, and FILTER Key. FUNCTIONS: AUTO Switch Off, Battery Low, Over Range Pressure, Over 9999 Reading INdication, Differential or Gauge Measurement.

Can be used with the optional pressure test kit to allow checking or calibrating other pressure instruments. Retails new for $610 USD. E-mail us for pricing.

OMEGA FMA 1818 Mass Flowmeters for Sale

Dealer demo condition used flowmeter.

Monitors the flow of a variety of gases, from 0 - 10 SCCM up to 0 - 100 SLM. Has an integral 3.5" display and a 0 - 5VDC output. The display is tiltable over 90 degrees, and calibrated to read out directly in SCCM or SLM for nitrogen. Analog outputs of 0 to 5 VDC and 4 to 20 mA are available via the 9-pin "D" connector on the flowmeter body.

Has an aluminum/brass body. Retails new for $511 USD, see the OMEGA website. E-mail us for pricing.

Newport and OptoSigma Opto-Mechanic Elements

Newport/OptoSigma Opto-Mechanic Components for Sale

SOLD

Model 462 ULTRAlign XYZ Linear Stages, Model 460 XYZ Linear Stages, Tilt Platforms, Preset Stages, Baseplates, Brackets, Post Holders, Kinematic Bases, Optical Rails, Optical Carriers, Goniometers, Filter Holders, Lens Holders, etc. Email us for the complete list and pricing. All components in excellent condition.

Thermo Forma Console Clean Air WorkStation for Sale

Horizontal Laminar Air Workstation, creates ultra clean Class 100 (M3.5) air. Air particles are caught on a HEPA filter rated at 99.99% efficient for 0.3 micron particulates. The HEPA filtered air is directed horizontally across the work surface, no contaminanation from room air.

Cabinet style: Console, Work Surface Material: Stainless Steel; Built-In Spill Guard; Disposable 1" Fiberglass Prefilter; Meets Federal Standard 209E.

In excellent functional and cosmetic condition. E-mail us for pricing.

Return to top of page.

World Wide Delivery
We can ship any item around the world including Europe, the Middle East, and South America. Wherever you are, we'll get it to you, FAST!

Don't See What You're Looking for? Contact us!

Contact us now to let us know what your equipment needs are. Not all equipment pieces are listed on this page, so contact us for our most recent arrivals.
